Fujitsu fi-7600 - 100 ppm/200 ipm

Fujitsu fi-7600 - 100 ppm/200 ipm

About this item

  • FOR A4 LANDSCAPE DOCUMENTS - Scan large volumes of documents, thin paper, plastic card envelopes, and long page documents
  • UP TO 100 PPM - This fast scanning scanner provides stable and smooth scanning of large volumes and various types of paper; in color or monochrome
  • CAPACITY UP TO 300 SHEETS - The paper chute can hold up to 300 sheets, but can handle various thicknesses and sizes of paper
  • STRAIGHT PAPER PATH - The straight paper path structure is designed to assure stable scanning regardless of document conditions and types.
  • MINIMIZE DOCUMENT DAMAGE - Paper Protection function minimizes the risk of document damage and protects your important documents by detecting anomalies in sound and document length.

Specifications

Product Name fi-7600
Scanner Type ADF (Automatic Document Feeder) / Manual Feed, Duplex
Scanning Speed*1 (A4 Landscape)
(Color*2/Grayscale*2/Monochrome*3)
Simplex: 100 ppm (200/300 dpi)
Duplex: 200 ipm (200/300 dpi)
Scanning Speed*1 (A4 Portrait)
(Color*2/Grayscale*2/Monochrome*3 )
Simplex: 80 ppm (200/300 dpi)
Duplex: 160 ipm (200/300 dpi)
Image Sensor Type Color CCD x 2 (front x 1, back x 1)
Light Source White LED Array x 4 (front x 2, back x 2)
Optical Resolution 600 dpi
Output Resolution*4
(Color / Grayscale / Monochrome)
50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver)*5
Output Format Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit
Background Colors White / Black (selectable)
Document Size Maximum 304.8 x 431.8 mm (12 x 17 in.)
Minimum 50.8 x 69 mm (2 x 2.7 in.) (Portrait)
Long Page Scanning*6 5,588 mm (220 in.)
Paper Weight (Thickness) Paper 20 to 413 g/m2 (5.3 to 110 lb)
Less than A8 size: 128 to 209 g/m2 (34 to 56 lb)
Plastic Card Up to 1.4 mm*7
ADF Capacity*8 300 sheets (A4 80 g/m2 or Letter 20 lb)
Expected Daily Volume*9 44,000 sheets
Multifeed Detection Overlap detection (Ultrasonic sensor), Length detection
Paper Protection Lag detection, Sound detection (iSOP)*10
Interface USB 3.1 Gen 1 / USB 2.0 / USB 1.1
Power Requirements AC 100 to 240 V ±10 %
Power Consumption Operating Mode 64 W or less
Sleep Mode 1.7 W or less
Auto Standby (Off) Mode 0.35 W or less
Operating Environment Temperature 5 to 35 °C (41 to 95 °F)
Relative Humidity 20 to 80% (non-condensing)
Environmental Compliance ENERGY STAR®, RoHS
Dimensions*11 (W x D x H) 236 x 432 x 214 mm (9.3 x 17.0 x 8.4 in.)
Weight 11 kg (24 lb)
Supported Operating System Windows® 10*12, Windows® 8.1, Windows® 7, Windows Server® 2022, Windows Server® 2019, Windows Server® 2016, Windows Server® 2012 R2, Windows Server® 2012, Windows Server® 2008 R2, Windows Server® 2008*13
Included Software / Drivers PaperStream IP Driver (TWAIN/TWAIN x64/ISIS), WIA Driver*14, PaperStream Capture, PaperStream ClickScan*15, Software Operation Panel, Error Recovery Guide, ABBYY FineReader for ScanSnap™*15, Scanner Central Admin, 2D Barcode for PaperStream*15
Image Processing Functions Multi image output, Automatic color detection, Blank page detection, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, Dither, De-Screen, Emphasis, Dropout color (None/Red/Green/Blue/White/Saturation/Custom), sRGB output, Hole punch removal, Index tab cropping, Split image, De-Skew, Edge correction, Vertical streaks reduction, Cropping, Static threshold, Divide long page
Included Items Stacker, ADF paper chute, AC cable, AC adapter, USB cable, Setup DVD-ROM
  1. Actual scanning speeds are affected by data transmission and software processing times.
  2. Indicated speeds are from using JPEG compression.
  3. Indicated speeds are from using TIFF CCITT Group 4 compression.
  4. Selectable maximum density may vary depending on the length of the scanned document.
  5. Limitations may apply to the size of documents that can be scanned, depending on system environment, when scanning at high resolution (over 600 dpi).
  6. Capable of scanning documents that exceed Legal sheets in length. Long page scanning supports documents with lengths of up to 5,588 mm (220 in.) when the resolution is set to 200 dpi or less. Documents of up to 200 m (218.8 yd.) can be scanned if scans of long page documents are split into multiple pages.
  7. Capable of scanning up to 3 cards at a time when using the ADF. (Note: only one embossed card can be scanned at a time).
  8. Maximum capacity depends on paper weight and may vary.
  9. Numbers are calculated using scanning speeds and typical hours of scanner use, and are not meant to guarantee daily volume or unit durability.
  10. Intelligent Sonic Paper Protection.
  11. Excludes the ADF hopper and stacker.
  12. fi Series scanners do not run with Windows® 10 ARM-based PCs.
  13. Requires PaperStream IP 1.60.0 or earlier and PaperStream Capture 2.8.2 or earlier.
  14. Functions equivalent to those offered by PaperStream IP may not be available with the WIA Driver.
  15. Refer to the fi Series Support Site for driver/software downloads and full lineup of all supported operating system versions.
